Introduction to common industrial aluminum profile connectors

The connectors for industrial aluminum profiles mainly include built-in connectors, corner groove connectors, groove bar connectors, triangular connectors, and angled connectors. So how much do you know about them? Let's take a look together.

(1) Built in connectors are mainly used for cross or vertical connections of profiles. During assembly, installation process holes need to be drilled at the specified size position of the profile to embed the accessories. At the same time, the elastic nut should be placed in the groove of another profile, and then the bolt should be locked.

(2) There are two types of corner slot connectors, E-type and L-type, used for right angle connection of two profiles. During installation, insert both ends into the groove of the profile and lock them with set screws. Different corner slot connectors should be selected according to the groove width and connection method of the profile.

(3) Slot bar connector, used for straight-line extension connection between two profiles. During installation, it is inserted into the groove at the junction of the two profiles and then locked with a set screw.

(4) Triangle connector is a semi-circular profile connector that can connect two or three profiles together, and with a matching cover plate, it is simple and beautiful.

(5) Diagonal connector, used for connecting two profiles at a non 90 ° angle, hidden inside the profile during installation.

The above are five common connectors for industrial aluminum profiles and how they are generally connected. The specific matching of each type of industrial aluminum profile connector should be based on whether the selected industrial aluminum profile is classified according to European or national standards, and then the model should be selected for matching.
